The Molecular Orbital Diagram for Model 2: A Ground-Up Guide to Ground States
You’ve probably drawn a Lewis structure a hundred times. Consider this: dots for electrons, lines for bonds. Consider this: it works for a lot of things. But then you get to oxygen. Which means you draw O=O with two pairs of dots on each oxygen, all electrons neatly paired. And then a magnet comes along and pulls the container of O2 gas towards it. Violently.
Your Lewis structure is screaming that oxygen is diamagnetic—it shouldn’t be attracted to a magnet. But it is. Now, it’s paramagnetic. And that single, confusing fact is the entire reason we need a better model. A model that isn’t just about counting electrons, but about where they actually live*.
That model is Molecular Orbital Theory, and what we call "Model 2" is its most powerful and widely applicable version for diatomic molecules. Let’s figure out how to draw its ground state orbital diagrams, because once you do, the magnetic personality of oxygen finally makes sense.
## What Is "Model 2" in Molecular Orbital Theory?
First, let's get our terms straight. That said, "Model 2" isn't some obscure scientific classification. It’s the standard, full implementation of MO theory for homonuclear diatomic molecules—meaning molecules made of two of the same atom, like N₂, O₂, or F₂.
The core idea is simple: when two atoms bond, their atomic orbitals (AOs) don't just sit there. And they merge and combine to create a new set of molecular orbitals (MOs) that belong to the whole molecule. Because of that, think of it like two solo singers blending their voices into a duet. The duet has its own harmonies and dissonances that the solo parts never had.
These new MOs come in two flavors:
- Bonding Orbitals: Lower in energy than the original atomic orbitals. Electrons here hold the atoms together.
- Antibonding Orbitals: Higher in energy. They have a nodal plane between the nuclei, and electrons here actually work against the bond.
The "Model 2" part specifically refers to the complete energy ordering of these molecular orbitals. For diatomic molecules of elements from Boron (B) through Nitrogen (N)—so B₂, C₂, N₂—the energy order is one thing. Which means for Oxygen (O) and everything after it—O₂, F₂, Ne₂—the order changes slightly. This is the model that correctly predicts the properties of oxygen, and it’s the one we’ll focus on.
## Why Does the Ground State Diagram Matter?
The "ground state" is simply the lowest energy, most stable arrangement of a molecule's electrons. It's the default setting. Drawing the diagram for the ground state is like writing the correct recipe for a molecule.
- Magnetism: Will it be pulled by a magnet (paramagnetic) or pushed away (diamagnetic)? This depends entirely on whether the ground state has unpaired electrons.
- Bond Order: A number that tells you how strong and how short the bond is. Higher bond order = stronger, shorter bond.
- Stability: Does the molecule even want to exist? A negative or zero bond order means it’s not stable.
The oxygen paradox is the perfect example. Practically speaking, by drawing the correct ground state diagram for O₂, you see two unpaired electrons. That’s why it’s paramagnetic. The Lewis structure lied to you because it couldn't show you the reality of where those electrons reside.
## How to Draw a Model 2 Ground State Orbital Diagram: A Step-by-Step Walkthrough
Let’s build one from scratch. We’ll use oxygen (O₂) as our example because it’s the poster child for this model.
Step 1: Gather Your Ingredients.
- Identify the atoms: Two Oxygen atoms.
- Total valence electrons: Each O atom has 6 valence electrons (Group 16). So, O₂ has a total of 6 + 6 = 12 valence electrons to place in the diagram.
- Recall the Model 2 energy ordering: For O₂ and F₂, the correct energy order from lowest to highest is: σ2s < σ2s < σ2p < π2p = π2p < π2p = π2p < σ2p (Note: σ is a sigma bond, symmetric around the bond axis. π is a pi bond, with electron density above and below the axis. The asterisk * denotes an antibonding orbital.)
Step 2: Draw the Framework. On a piece of paper, draw two vertical columns. The left column represents the atomic orbitals of one oxygen atom; the right column represents the other. In the middle, you’ll draw the molecular orbitals, stacked vertically according to the energy order we just listed.
Continue exploring with our guides on when and where was neon discovered and will it sink or will it float.
Step 3: Place the Atomic Orbitals. Each oxygen atom has the same valence atomic orbitals: a 2s orbital and three 2p orbitals (2px, 2py, 2pz). Draw them on the left and right sides of your diagram. The 2s orbitals should be lower in energy than the 2p orbitals.
Step 4: Combine and Fill the Molecular Orbitals. Now, for the middle section. Draw lines connecting the atomic orbitals to their corresponding molecular orbitals. This shows how they combine.
- The two 2s orbitals combine to form a lower-energy σ2s (bonding) and a higher-energy σ*2s (antibonding).
- The two 2pz orbitals (aligned along the bond axis) combine to form a σ2p (bonding) and a σ*2p (antibonding).
- The two 2px orbitals combine to form a π2p bonding pair, and the two 2py orbitals combine to form another π2p bonding pair. Because they are perpendicular to each other, they are degenerate (same energy). Their antibonding counterparts, π*2p, are also degenerate.
Step 5: Add the Electrons—the Crucial Part. This is where the ground state is defined. You have 12 electrons to place. Follow the Aufbau principle (lowest energy first) and Hund's rule (fill degenerate orbitals singly before pairing up).
- Fill σ2s with 2 electrons (one pair).
- Fill σ*2s with 2 electrons (one pair). (That’s 4 electrons used. The 2s subshell is effectively "full" and won't contribute much to bonding.)
- Fill σ2p with 2 electrons (one pair). (6 electrons used.)
- Now, you have two degenerate π2p orbitals. Place one electron in each, with their spins parallel (both spin-up, for example). This is Hund's rule in action, and it’s why oxygen is paramagnetic. (8 electrons used.)
5.5. Place the remaining four electrons in the π antibonding set.*
The two degenerate π₂p orbitals are next in energy. According to Hund’s rule, place one electron in each orbital with parallel spins before any pairing occurs. This uses two more electrons, bringing the total to 10. The final two electrons then pair up, one in each π₂p orbital, giving each antibonding orbital a filled pair. All 12 valence electrons are now placed.
Resulting electron configuration for O₂ (valence only):
σ₂s² σ₂s² σ₂p² π₂p⁴ π₂p²
Bond order calculation:
Bond order = (number of bonding electrons − number of antibonding electrons)/2
Bonding electrons = σ₂s² (2) + σ₂p² (2) + π₂p⁴ (4) = 8
Antibonding electrons = σ₂s² (2) + π₂p² (2) = 4
Bond order = (8 − 4)/2 = 2
Thus O₂ possesses a double bond, consistent with its relatively short bond length and high bond dissociation energy. The two unpaired electrons residing in the degenerate π*₂p orbitals give O₂ a triplet ground state (³Σ_g⁻) and render it paramagnetic—a property that is readily observed in experiments such as the attraction of liquid O₂ to a magnetic field.
Conclusion
By following the Aufbau principle, Hund’s rule, and the correct energy ordering for the O₂ molecule, the molecular‑orbital diagram predicts a double bond and two unpaired electrons. This theoretical picture matches the experimentally observed bond strength, bond length, and paramagnetic behavior of molecular oxygen, demonstrating the power of MO theory to explain fundamental chemical properties.
